The Soehnle Professional Terminal 3035 is a calibratable terminal for use in scales and weighing
systems with commercially available DMS weighing and load cells.
Up to three analog measurement locations (scales) can be internally connected at the same
time. Up to 29 external measurement locations are possible via CAN bus. Yet another scale can
be connected e.g. as reference scale with the serial interface. Additional data can be entered
with the keypad. Various interface options are available for connecting printers, IT, readers,
data storage, and external PC keypads.
The Soehnle Professional Terminal 3035 was designed for efficient operations even in rough
environments. It is rugged, easy to clean, flexible, and fast. A logical design and user interface
facilitate fast learning and intuitive terminal operations. The terminal design adjusts to your
specific needs and supports you in your job.
Before operating the terminal, please read the information shown in the user manual with care. It
contains important information about the installation, the intended uses, and maintenance of the
terminal.
The manufacturer is not liable if the following instructions are not observed:
When using electrical components under elevated safety requirements, the corresponding
regulations must be adhered to. Never perform service work on the terminal while the unit is under
power. The product warranty is null and void if the terminal is installed inappropriately.
• The terminal 3035 is not approved for ATEX environments. A custom version is available
for ATEX zones 2 and 22.
• The rated mains voltage is 100 – 240 volts. The power outlet must be grounded and
easily accessible.
• The terminal must only be opened by trained Soehnle Industrial Solutions service
technicians. The housing contains no user-serviceable components. Unauthorized
manipulations render the product warranty null and void.
• Only a trained Soehnle Industrial Solutions service location is authorized to make repairs
and to replace or install components.
• The terminal must be taken out of service if the power cable is damaged. Disconnect the
power supply and contact a Soehnle Industrial Solutions service location.
• The attached security labels must not be damaged if the terminal is used for functions
with calibration mandate.
Contact your Soehnle Industrial Solutions service partner if you experience problems.
