in d with number keypad
The number of number increments by which the scale must be relieved during the
totaling transaction, therefore allowing the next weight to the saved to totaling
memory. If the scale is not relieved, the weight value is not saved to the totaling
memory, and the error message "Error 55 - Place Weight" is displayed.
Between 0 and 30 number increments can be specified. On 0, totaling is possible as
long as the scale has not settled once.
Factory default: 15 number increments
Fixed reference
weight values
fixed reference weight values
Selecting available fixed values from the list
Page with F3 and F4 Arrow keys.
Retrieve the desired fixed value with F6 Edit
Edit an existing fixed value from the list
Edit the highlighted fixed value with F6.
Parameter name is highlighted; retrieve with F6 Edit,
enter with keypad
. Save entry with F6.
(cancel without saving the entry with F5 Cancel)
Other parameters are edited in the same manner.
Deleting an existing fixed value
Page with F3 and F4 Arrow keys.
Delete the highlighted fixed value with F2 Delete.
The resulting gap in the sequential numbering will be closed.
Press F1 New.
The memory location number is assigned by the equipment. The first number in
parenthesis indicates the free memory locations, the second number indicates the
memory locations with assigned fixed values.
Parameter name is highlighted; retrieve with F6 Edit, enter with keypad. Save entry
with F6 Save.
(cancel without saving the entry with F5 Cancel)
Other parameters are edited in the same manner.
Closing the fixed value list
The list is closed with the F5 Back key.
whether fixed values are retrieved with sequential memory location numbers
or part numbers.
Factory default: Part number
do not execute or execute
Execute deletes all fixed values in Ref Fix memory.
do not execute or execute
Execute enables the switching function for an external control light or control. An
I/O card must be installed to control the switching processes.
off or on
If start mode is enabled, the scale freezes the value after reaching the respectively
enabled switching point, and as a result also freezes the signal. The scale can be
relieved without disabling the switching point, and thus without unintentionally
starting a new transaction. The frozen state is only lifted by pressing the F6 Start
key in the Control Functions level.
