3.3.2 Direct cable connection
To test a live PROFIBUS, you will need additional D-sub service interfaces of the type BC-PBMB-PB-S
(see Service interfaces for PROFIBUS DP ).
Figure 18: Service interfacesprovide connection points at direct cable connection
