Chapter 13 - Technical Data
Copyright 2016 Softing Industrial Automation GmbH
55
13
Technical Data
Via external AC adapter 110 V .. 240 VAC 50/60 Hz (galvanically isolated)
or built-in three cells lithium ion accumulator with 11.1 VDC. The
rechargeable battery has a run-time of up to 5 hours (run-time depends
on the executed test functions and rate of wear of the rechargeable
battery) Battery is charged via external AC adapter.
PROFIBUS D-sub connector (female), 9-pin, switchable power supply for
ext. bus termination Bus termination
Protocol and frame analysis: PROFIBUS DP and DPV1, automatic baud rate
detection 9.6 kbit/s .. 12 Mbit/s</t2>
Signal analysis:
PROFIBUS DP, DPV1, FMS and MPI;
signal quality index 0 .. 5000 determined from signal waveform as well
as signal/noise ration and rise time; Signal sampling with 8/16 samples per
bit
Oscillogram display:
test range ±5V at 10 mV resolution (differential), 0V…15V at 15mV
resolution (A or B to DGND)
Sampling rate up to 384 MSamples/s,
for signal details: 2,400 sampled points, for oscillogram analysis 8,192
sampled points
Topology scan: active, maximum distance 230 m, accuracy ±2 m
Cable test: active, permitted cable segment length 5 m ... 1500 m,
accuracy 5%</t2>
V 2.0, high speed 480 Mbit/s, galvanically isolated
IN: L=0 .. 0,8 V; H=2,4 .. 24 V; pulse > 10 µs, active high
OUT: ca. 5 V, active low (connection to storage oscilloscope)
3 network directories for storing Quick Tests, cable tests and trend logs
Trend logging max. 99 hours
Test tool without cable: approx. 0.75 kg,
complete with carrying case, without accessories: approx. 4.2 kg
Permissible
ambient conditions
Operating temperature 0 ... 50 °C
Storage temperature -20 ... 70 °C
Air humidity 10 ... 90 % without condensation
Via graphical color display, four function keys and scroll wheel including
central push-button or via PC/notebook.
Display languages available: German, English
PROFIBUS Diagnostics Suite, see separate documentation
