109
Display Description
Status Current operating status
Warning Current warning message
Commissioning Date of initial start-up
Operating hours Total operating hours in mains operation
Mac address Mac address of the inverter
7.7 Operating status
The status message displayed on the graphics display describes the current operating
status of the inverter. Each status message relates to one of ve possible operating sta-
tuses. The status LED has different colors with which to indicate one of these operating
statuses.
In addition to the status messages, the inverter also displays warnings. Warnings result
from device errors or external malfunctions. The inverter continues to feed power into
the mains, but it is possible that yield is reduced. Warnings are independent of the oper-
ating status and are displayed on the graphics display alternately with the current status
message.
Status LED Operating status Description
Off
- Inverter is switched off
Flashes green
Booting Inverter is starting up
Green
Mains operation Mains feed-in (normal operation)
Flashes orange
-
Warning → no grid disconnection
Orange
Fault
External fault → grid disconnection
Red
Error
Device error → grid disconnection
Flashes red
Blocked
Inverter is blocked → grid disconnection
The "Fault", "Error", and "Blocked" operating status messages, as well as the warnings,
usually require certain measures to be carried out by the qualied electrician in charge
(see section 8).
