SolarMax MT Series - Electrical Connection

16
Installation plate
235
[mm]
100
10
7
2
1
1
For the other measurements see Section 3.2.
1
Holes for padlock (against theft)
2
Recesses for lock with splint
4.6 Electrical connection
The MT series inverters have the following connection options:
1 2 3 44 5 6 7
