SolarMax MT Series - Page 38

38
Function / Parameter Description Unit
t Vac max 1 Release time for maximum admissible mains voltage ms
Vac min 2 Minimum admissible mains voltage (second limit) V
t Vac min 2 Release time for minimum admissible mains voltage ms
Vac max 2 Maximum admissible mains voltage (second limit) V
t Vac max 2 Release time for maximum admissible mains voltage ms
Vac 10 min max Maximum admissible average value of the mains volt-
age over the last 10 minutes
V
Iac mean max Maximum permissible DC component in the mains
current
A
f min 1 Minimum admissible mains frequency (rst limit) Hz
t f min 1 Release time for minimum admissible mains frequency ms
f max 1 Maximum admissible mains frequency (rst limit) Hz
t f max 1 Release time for maximum admissible mains frequency ms
f min 2 Minimum admissible mains frequency (second limit) Hz
t f min 2 Release time for minimum admissible mains frequency ms
f max 2 Maximum admissible mains frequency (second limit) Hz
t f max 2 Release time for maximum admissible mains frequency ms
df/dt max Maximum admissible change of the mains frequency Hz/s
Ierr max Maximum admissible leakage current (effective value)
on the DC end
mA
Island detection Immediate grid disconnection when island operation
detected (Anti-Islanding)
Inactive/
on
Monit. ext. input The status signalling contact is congured for monitor-
ing an external input.
Inactive/
on
Restart delay Delay time before grid reconnection upon previous
failure-related grid disconnection.
s
Pac progression Maximum increase of the effective power during grid
reconnection upon previous failure-related grid discon-
nection.
%/min
Soft Start Maximum increase of the effective power at grid con-
nection. This gradient, if activated, is always effective,
as opposed to “Pac Progression” (even during restart
in the morning).
W/s
Mains check Additional mains check before connecting to the grid Inactive/
on
- Vac MC max Maximum admissible mains voltage V
- Vac MC min Minimum admissible mains voltage V
