142
Appendix
Settings for Adapter Box
Setting path: Menu>Setting>Advance Setting>Internal485
a. Select and enter Internal485 interface.
b. Select the AdapBox G2 and set the Braud Rate and corresponding Address.
=====Internal485=====
>Function Control
AdapBoxG2
>Braud Rate
9600
>AdapBoxG2 Addr:
70
=====Internal485===== =====Internal485=====
NOTICE!
• When two equipments need to be connected at the same time, the braud rate and
address of the two equipments shall be set to the same.
c. Check the connectiong status.
=====Internal485=====
>AdapBox G2 COM STAT
Connected
NOTICE!
• Please refer to the
Adapter Box G2 User Manual
for specifc parameter setting and
wiring.
To Next Page
