Mechanical Installation

Step 6: Secure the inverter to the bracket with M5 screw,

0.8± 0.1 N·m

Figure 7-10 Securing the inverter

Step 7: (Optional) For safety reason, install an anti-theft lock. Please note that the lock

is not in the scope of delivery. Prepare it suitable for the lock hole diameter (

mm) by yourself. Keep the key to the lock in a safe place.

Figure 7-11 Locking the inverter
