Electrical Connection

Battery connection with BMS-Parallel Box-II G2 (The BMS-Parallel Box-II G2

can be used with T-BAT-SYS-HV-5.8) (Coming soon)

T-BAT H5.8

BMS-Parallel Box-II G2

Inverter

• With BMS-Parallel Box-II G2,

up to 16 battery modules

can be connected.

BAT-

BAT+

COMM

T-BAT H5.8HV11550

HV11550

HV11550 HV11550

Figure 7-24 Battery connection with BMS-Parallel Box-II G2

NOTICE!

• Considering factors such as cost, maximizing battery performance, and meeting the

voltage requirements of the inverter, please choose a suitable battery connection

scheme.

• It is possible to expand the capacity by adding batteries of the same model, Different

models of batteries are not supported for expansion.

SolaX Power X3-ULTRA Series User Manual
