1 Getting Started
1-3
Equipment
Curve Tracer Equipment (PVA-1500xx, PVA-1000S, PVA-600
+
)
• I-V Measurement Unit
• Soft Case
• Wireless USB Adapter (not required or provided with PVA-1500xx)
• PVA Software Application (available at http://www.solmetric.com/downloads-
pva.html)
• AC Wall Plug Charger
• MC-4 to MC-4 Connector-Saver Cable (2)
• Test leads, MC-4 to 4mm banana plug with plug-on alligator clips (for PVA-
1000S and PVA-600+, rated to 1000V DC, 1 set)
• Test leads, MC4-EVO2 to 4mm banana plug with plug-on alligator clips (for
PVA-1500xx, rated to 1500V DC, 1 set)
• MC-4 connector tool
• User’s Guide — (available in the HELP menu of the PVA software and from
http://www.solmetric.com/downloads-pva.html).
• Quick Reference Card
SolSensor Equipment
• SolSensor unit (The PVA-1500S operates with the SolSensor 300 and the PVA-
1500V2/V3/V4/T operates with the SolSensor 300V2).
• K-type thermocouple temperature sensors (2)
• Wireless USB Adapter (not required or included for PVA-1500xx)
• Soft Case (unless PVA kit was purchased with the transit case option)
• Module Frame Clamp
• AC Wall Plug Charger
• Adhesive discs for thermocouple attachment (50)
• SolSensor tool lanyard
• Irradiance sensor cleaning supplies (micro-fiber cloth and distilled water spray)
