MPI-
536
–
USER MANUAL
29
3.4.2
Fault loop parameters in the L-
N and L-L circuits
Connect test leads according to the drawing
or
for measurement in the L
-N circuit,
for measurement in t
he L-L circuit.
Select item
Z
L-N
, L
-
L
.
The
measurement
s
creen
will
a
p-
pear.
Live mode
U
L-N
–
current
voltage
betwe
en
phase and neutral condu
ctors
f
–
current frequency on the
tested
object
Enter the measurement sett
ings in accordance with
section 3.4.1
.
30
32
