MPI-536 – USER MANUAL
Read the measurement result.
The result is the arithmetic mean
of the values of two measure-
ments at a current of 200 mA with
opposite polarities R
F
and R
R
.
Signal lights for the limit
(step )
the result is within the set
limit
the result is outside the set
limit
assessment not possible
After selecting the bar on the
right side, a menu will slide out
with additional measurement re-
sults.
R
F
– result obtained for a posi-
tive polarity of the measuring cur-
rent
R
R
– result obtained for a nega-
tive polarity of the measuring cur-
rent
Selecting the bar hides the
menu.
Save the measurement to the meter memory using the icon. A detailed description of
memory management is contained in section 5.3. The last measurement can be recalled us-
ing the icon.
Press the START button in order
to start the next measurement
without disconnecting test leads
from the object and proceed to
step .
NOTE!
Display of symbols indicates that the tested object is live. The
measurement is blocked. The meter must be immediately disconnected from the
object.
