Sony Ericsson W810 - Core Component Replacements (Covers to Frame)

Working Instruction, Mechanical
3/000 21-1/FEA 209 544/108 B
© Sony Ericsson Mobile Communications AB
16(53)
3.1 Battery Cover
Follow the 2.1.1 Disassembly instructions!
Prepare the new battery cover.
Follow the 4.1.7 Reassembly instructions!
3.2 Antenna Cover
Follow the 2.1.1 – 2.1.2 Disassembly instructions!
Prepare the new antenna cover.
Install an external antenna plug as described in 3.29
Follow the 4.1.6 – 4.1.7 Reassembly instructions!
3.3 Front
Follow the 2.1.1 – 2.1.3 Disassembly instructions!
Prepare the new front.
Follow the 4.1.5 – 4.1.7 Reassembly instructions!
3.4 Keypad
Follow the 2.1.1 – 2.1.4 Disassembly instructions!
Prepare the new keypad.
Follow the 4.1.4 – 4.1.7 Reassembly instructions!
3.5 LCD
Follow the 2.1.1 – 2.1.6 Disassembly instructions!
Prepare the new LCD.
Follow the 4.1.2 – 4.1.7 Reassembly instructions!
3.6 Frame
Follow the 2.1.1 – 2.1.7 Disassembly instructions!
Remove the parts as described in 3.7 – 3.17 & 3.28
Prepare the new frame.
Install the parts as described in 3.7 – 3.17 & 3.27, 3.28, 3.30
Follow the 4.1.1 – 4.1.7 Reassembly instructions!
