Sony Ericsson W810 - Gasket, System Connector

Working Instruction, Mechanical
3/000 21-1/FEA 209 544/108 B
© Sony Ericsson Mobile Communications AB
33(53)
3.21 Gasket, system connector
Follow the 2.1.1 – 2.1.7 Disassembly instructions!
Remove the system connector as described in 3.19!
Remove the system connector gasket …
by pulling it out from the PBA with the tweezers.
Install a new system connector gasket by pushing it onto
the PBA with the tweezers.
Install the system connector as described in 3.19!
Follow the 4.1.1 – 4.1.7 Reassembly instructions!
