Working Instruction
,
Mechanical
3/000 21-1/FEA 209
544/108 B
©
Sony Ericss
on Mobile
Communi
cations AB
49(53)
4.1.4 Keyp
ad
There are two guiding pegs on the
keypad
…
to be placed into two holes on the key foil …
when the
keypad
is properly installed.
48
50
