44(53)
4 Reassembly
After replacing a part being listed in Replacements, the instruction of that section usually ends by
directing you to this Reassembly section with a specification of the instructions you have to carry out
in order to reassemble the phone.
4.1 Overview
The reassembly is done in the following sequence:
1. PBA
2. LCD
3. Plastic Carrier & Key Foil ass’y
4. Keypad
5. Front
6. Antenna Cover
7. Battery (a) and Battery Cover (b)
Start
Done
