Working Instruction, Mechanical
3/000 21-1/FEA 209 544/108 B
© Sony Ericsson Mobile Communications AB
6(53)
2 Disassembly
When you are going to replace a part being listed in Replacements, the instruction of that section
usually begins by directing you to this Disassembly section with a specification of the instructions you
have to carry out in order to disassemble the phone as far as needed before returning to
Replacements for the actual replacement.
2.1 Overview
The disassembly is done in the following sequence:
1. Battery Cover (a) and Battery (b)
2. Antenna Cover
3. Front
4. Keypad
5. Plastic Carrier & Key Foil ass’y
6. LCD
7. PBA
