3.13 IrDA Window
Follow the 2.1.1 – 2.1.7 Disassembly instructions!
Remove the IrDA window by using the ‘flex film assembly
tool’ or your fingers.
Install the IrDA window by using the ‘flex film assembly tool’
or your fingers.
Follow the 4.1.1 – 4.1.7 Reassembly instructions!
