1-2
DNW-A220
DNW-A220P
1-2. Connection Connectors/Cables
Connection made with the connector panels during installation or service, should be made with the
connectors or complete cable assemblies specified in the following list, or equivalent parts.
Panel indication Connection connector (Sony P/N) Connection cable (Sony P/N)
VIDEO REF IN Plug, BNC (1-564-742-11) RG-59B/U cable
VIDEO INPUT
VIDEO OUTPUT
TC IN
TC OUT
SDI IN Plug, BNC (1-564-742-11) BNC coaxial cable
SDI OUT (1-783-090-11:supplied with DNW-A220/A220P) or
BELDEN 8281 cable (Maximum cable length: 200m)
AUDIO INPUT XLR 3P, MALE (1-508-084-00) –––––––
AUDIO OUTPUT XLR 3P, FEMALE (1-508-083-00) –––––––
MONITOR OUTPUT
DC IN XLR 4P, FEMALE (1-508-362-00) DC power cord (1-551-577-00:supplied with AC-550/
550CE)
DC OUT Plug 4P MALE (1-566-425-11) –––––––
REMOTE Plug 9P MALE (1-560-651-00) 9P remote control cable
Shell, Junction 9P (1-561-749-00) (1-783-089-11:supplied withDNW-A220/A220P) or
RCC-5G(5 m)/10G(10 m)/30G(30 m)
AUX Plug 6P MALE (1-560-078-00) –––––––
HEADPHONES JM-60 stereo phone plug –––––––
(commercially available)
