2-5
DNW-A220
DNW-A220P
ERROR-02 REEL TROUBLE - 2
(REEL TROUBLE)
Description: Tape slacking or tape breaking was detected in SEARCH, FF, or REW mode.
Detecting conditions: 1) When the take-up value is lower than the specified value with respect to the
tape supply value.
2) When the detect voltage of the supply tension sensor is lower than the
specification continuously for some seconds.
3) When the supply reel and take-up reel do not coincide in rotation direction
continuously for more than five seconds.
Sub error message: None
Possible causes: . Cassette compartment trouble or installation defect
* The reel did not rotate because the cassette was lifted-up from the speci-
fied position.
. FG sensor trouble in supply reel motor or take-up reel
. Supply reel FG waveform shaper circuit (SV-194 board) trouble
. Supply or take-up reel motor trouble
. Supply reel motor drive circuit (SV-194 board) trouble
. Capstan motor trouble
. Capstan motor drive circuit (SV-194 board) trouble
. Capstan FG waveform shaper circuit (SV-194 board) trouble
. Take-up torque insufficiency during REW due to supply tension sensor or
supply tension detect circuit (SR-50 board) trouble
. Servo adjustment defect on capstan, reel, and supply tension sensor
. Supply reel brake trouble
. Supply reel brake solenoid drive circuit (SV-194 board) trouble
. Harness disconnection
. Reel table height adjustment defect
. Tape path and drum troubles
. Tape abnormality (The winding state has a problem.)
Protecting operation: Enters the protection mode. The normal state may be returned after the protec-
tion mode is entered at the end of the tape.
c
Be sure to take out the cassette manually (refer to Section 1-11). Do not turn on
the power again without taking out the cassette. This may damage the tape.
2-2. Details of Error Messages
