3-53
DNW-A220
DNW-A220P
3-4-6. INT AUDIO SG LEVEL (M37)
This menu can change the output level of an internal audio SG.
The SG level can be selected from among the following. (The factor setting is 20 dB.)
20 dB, 18 dB, 16 dB, 15dB, 14dB, 12 dB, 9 dB
SG level setting
(1) Turn the JOG dial while pressing the search button, and the desired setting is then displayed.
. Message “Push SET Button” is displayed on only the LCD monitor when the setting is changed.
. To cancel the setting, push the MENU button to terminate this menu.
(2) Push the SET button to save the changed setting.
. Message “Saving...” is displayed on only the LCD monitor. If no abnormality is found, the display
changes to “Save Complete” after a few seconds.
To turn off “Save Complete”, turn the JOG dial.
3-4. OTHERS CHECK Mode (M3)
3-4-6. INT AUDIO SG LEVEL (M37)
M37:INT AUDIO SG LEVEL
20dB
*
M3:OTHERS
