DNW-A220
DNW-A220P
1-16. Settings for External Editors
1-16-1. Time Code Settings for Recorder
When editing with an editor capable of the 1st-edit (BVE-2000)
. Time code operation block on the control panel
INT/EXT switch 8 INT
PRESET/REGEN switch 8 PRESET
F-RUN/R-RUN switch 8 F-RUN
When editing directly from VTR to VTR
n
Make sure that the setting of ITEM-610 on the setup menu is as follows;
. ITEM-610: REGEN CONTROL MODE 8 0: auto edit
. Time code operation block on the control panel
INT/EXT switch 8 INT
PRESET/REGEN switch 8 PRESET
F-RUN/R-RUN switch 8 R-RUN
1-16-2. VTR Constant Settings for External Editors
The following constants are standard for each type and system listed.
When using an external editor which requires the VTR constants, use the settings listed. VTR constants
must also be set when switching between the 525 and 625 line systems.
VTR CONSTANT 1 VTR CONSTANT 2
Data No. Data No.
Type / System 12345678 12345678
Player : 525/60 system B0 4C 00 96 07 07 04 8B 0A 08 FB 00 8D 3D FF 4C
Player : 625/50 system B1 4C 00 7D 07 07 04 8B 0A 07 FB 00 8F 4B FF 4C
Recorder : 525/60 system B0 4A 00 96 07 07 04 8B 0A 08 FB 00 8D 3D FF 4C
Recorder :625/50 system B1 4A 00 7D 07 07 04 8B 0A 07 FB 00 8F 4B FF 4C
Values are represented in hexadecimal
m
1. Set the data No. 8 of VTR CONSTANT 1 to 0A for the following editors.
. BVE-900 ROM version 1.08 or lower
. BVE-600 ROM version 1.01 or lower
2. If the unit is controlled by the editor, be sure to set ITEM-401 on the setup menu as follows;
. ITEM-401: FUNCTION MODE AFTER CUE-UP 8 0: stop
