3-7
DNW-A220
DNW-A220P
SERVO CHECK
C00-03:SERVO CHECK
*
SERVO CHECK
C00:INPUT CHECK
C01:MOTOR CHECK
C02:PLUNGER SOL. CHECK
C03:REEL/CAPSTAN MOTOR
& FG CHECK
*
[SET]
[MENU]
C0: SERVO CHECK
This submode is used to check the servo system of a VTR.
For more details, refer to Section 3-2-2.
Title Page Description
C00 : INPUT CHECK — Check menu of sensors (not including a part of sensors)
C000 : CASSETTE SW 3-15 Checks the cassette tab and REC inhibit sensors.
C001 : CASSETTE COMP. 3-16 Checks the cassette-in and cassette size sensors.
LOCK SW
C002 : TOP/END SENSOR 3-17 Checks the tape top and tape end sensors.
C003 : DEW SENSOR 3-18 Checks the dew condensation sensors.
C01 : MOTOR CHECK — Check menu of motors (except a fan motor) and partial sensors
C010 : S REEL MOTOR 3-19 Checks the S reel motor.
C011 : FUNCTION CAM MOTOR 3-20 Checks the threading motor and threading/unthreading end
sensors.
C012 : CAPSTAN MOTOR 3-22 Automatically checks the capstan motor.
C013 : DRUM MOTOR 3-23 Automatically checks the drum motor.
C02 : PLUNGER SOL. CHECK — Check menu of solenoids
C020 : S REEL BRAKE 3-24 Checks the S reel brake solenoid.
C03 : REEL/CAPSTAN MOTOR & 3-25 Continuous check menu of reel and capstan motors
FG CHECK
3-2. TAPE Maintenance Mode (M0)
3-2-1. Overviews
