2-6
DNW-A220
DNW-A220P
ERROR-03 REEL TROUBLE - 3
(REEL TROUBLE)
Description: Tape slacking, or tape breaking was detected in the REC or PLAY mode.
Detecting conditions: 1) When the take-up value is lower than the specified value with respect to the
tape supply value.
2) When the tension value calculated from the supply tension sensor output is
less than 15 g continuously for more than three seconds.
3) When the supply reel and take-up reel do not coincide in rotation direction
continuously for more than five seconds.
Sub error message: None
Possible causes: . Cassette compartment trouble or installation defect
* The reel did not rotate because the cassette was lifted-up from the speci-
fied position.
. FG sensor trouble in supply reel motor or take-up reel
. Supply or take-up reel FG waveform shaper circuit (SV-194 board) trouble
. Supply reel motor trouble
. Supply reel motor drive circuit (SV-194 board) trouble
. Capstan motor trouble
. Capstan motor drive circuit (SV-194 board) trouble
. Capstan FG waveform shaper circuit (SV-194 board) trouble
. Servo adjustment defect on capstan, reel, and supply tension sensor
. Supply reel brake trouble
. Supply reel brake solenoid drive circuit (SV-194 board) trouble
. Harness disconnection
. Reel table height adjustment defect
. Tape path and drum troubles
. Tape abnormality (The winding state has a problem.)
Protecting operation: Stop the tape transport and enters the rest state.
c
Be sure to take out the cassette manually (refer to Section 1-11). Do not turn on
the power again without taking out the cassette. This may damage the tape.
2-2. Details of Error Messages
