1-42
DNW-A220
DNW-A220P
1-15. Fixtures and Adjustment Equipment List
1-15. Fixtures and Adjustment Equipment List
1-15-1. Fixtures
n The tools are used only in the maintenance manual Part 2 are also described.
Fig. Part No. Name For use Description
*
1 A-8316-723-A Extension board (EX-617) Extension of plug-in boards P2
A-8321-000-A Extension board (EX-706) Extension of plug-in boards P2
2 A-8317-304-A HN-257 mounted circuit board Tape path alignment P2
3 J-6035-070-A Extruction tool (for PLCC socket) Extruction of PLCC IC P2
4 J-6080-840-A Inspection mirror Tape curl check P2
5 J-6252-520-A Torque screwdriver Tightening screws of cabinet P1/P2
(12 kgf.cm) (1.2 N.m) [JB-5252] for installing and removing
J-6325-400-A Torque screwdriver (3 kgf.cm) Tightening screws (for M1.4 and M2 bit) P1/P2
6 J-6325-110-A Torque screwdriver bit (for M1.4) Tightening screws on mech. deck (l = 75 mm) P1/P2
7 J-6325-380-A Torque screwdriver bit (for M2) Tightening screws on drum, capstan, P1/P2
reel motor and boards (l = 162 mm)
8 J-6322-420-A Tape guide adjustment driver (45) Tape path adjustment P2
9 J-6323-530-A Stop washer fastening tool Installation of stop washer P2
10 J-6323-890-A Torque cassette (FWD BACK TEN.) [MW-389] FWD back tension REV back tension measurement P2
11 J-6324-150-A Reel table height adjustment tool [MW-415] Reel height check P2
12 J-6326-120-A Hexagon bit (for torque driver) Tightening screws on mechanical deck for P2
installing and removing (d = 1.5 mm, l = 85 mm)
13 J-6332-240-A VISC phase adjusting tool VISC alignment for PAL system P2
14 J-6530-380-A Conversion cable, 6P - 9P Rewrite internal software P2
15 J-7032-610-A Cassette reference plate Reel height adjustment P2
16 3-184-527-01 Cleaning cloth (15 cmx15 cm) Cleaning P1/P2
17 3-649-266-01 Parallel pin (d = 1.6 mm) Fixing position of cam gear P2
3-703-358-04 Parallel pin (d = 2.0 mm) Fixing position of threading gear/drawing arm P2
when installing
18 7-432-114-11 Screw locking compound (200g) Inhibits loosening of screws P2
19 7-651-000-10 Sony grease SGL-601 (50 g) P2
7-651-000-11 Sony grease SGL-801 (50 g) P1/P2
7-651-001-59 Grease PG-662 (20 g) P2
20 7-661-018-18 Diamond oil NT-68 (50 ml) P2
21 7-700-751-01 Nut driver (s = 4.5 mm) CTL/AT head height adjustment P2
22 8-960-075-01 Alignment tape, SR5-1 Video/audio alignment (for 525/60 system) P2
8-960-075-11 Alignment tape, SR2-1 Servo alignment (for 525/60 system) P2
8-960-075-51 Alignment tape, SR5-1P Video/audio alignment (for 625/50 system) P2
8-960-075-61 Alignment tape, SR2-1P Servo alignment (for 625/50 system) P2
23 8-960-096-01 Alignment tape, CR2-1B Tracking alignment (for analog Betacam, NTSC) P2
8-960-096-41 Alignment tape, CR5-1B (METAL) Video alignment (for analog Betacam, NTSC) P2
8-960-096-51 Alignment tape, CR2-1B PS Tracking alignment (for analog Betacam, PAL) P2
8-960-097-44 Alignment tape, CR5-2A (OXIDE) Betacam video alignment (for analog Betacam, NTSC) P2
8-960-097-45 Alignment tape, CR8-1A (OXIDE) Betacam audio alignment (for analog Betacam, NTSC) P2
8-960-096-91 Alignment tape, CR5-1B PS (METAL) Video alignment (for analog Betacam, PAL) P2
8-960-096-86 Alignment tape, CR8-1B PS (METAL) Audio alignment (for analog Betacam, PAL) P2
8-960-098-44 Alignment tape, CR5-2A PS (OXIDE) Video alignment (for analog Betacam, PAL) P2
8-960-098-45 Alignment tape, CR8-1A PS (OXIDE) Audio alignment (for analog Betacam, PAL) P2
