A-3
DNW-A220
DNW-A220P
A. Setting Check Sheet
Internal Switches
nNever change setting of factory-use switches.
Board Switch No. : Name Factory setting Setting
AU-249 S1 1-4 : Factory use OFF (OPEN) _
DM-114/ S101 : Y EQ TEST NORMAL POSITION _
DM-114P S301 : C EQ TEST NORMAL POSITION _
S501 : Factory use ON _
S901 1 : RF adjusting switch OFF (OPEN) _
2 : Factory use OFF (OPEN) _
3 : AGC OFF OFF (OPEN) _
4 : Factory use OFF (OPEN) _
S1701 1 : Y MUTE OFF (OPEN)
2-3 : Factory use OFF (OPEN) _
4 : C MUTE OFF (OPEN)
5 : COMB OFF (OPEN)
6-8 : Factory use OFF (OPEN) _
S1801 1 : D CLP OFF OFF (OPEN)
2-4 : Factory use OFF (OPEN) _
PA-218 S500 : CH1 HEAD TUNE Switch Used during adjustment _
S600 : CH2 HEAD TUNE Switch Used during adjustment _
SV-194 S100 1
*1
: CASSETTE COMPARTMENT LOCK OFF (OPEN) _
2
*2
: SERVO ERR NOT DET OFF (OPEN) _
3 : Factory use OFF (OPEN) _
4 : AUTO-TRACKING OFF OFF (OPEN) _
5-6 : Factory use OFF (OPEN) _
SY-259/259A S201 1 : EXTENDED MENU OFF (OPEN)
2 : MAINTE MODE ACCESS OFF (OPEN)
3-8 : Factory use OFF (OPEN) _
S202 1-4 : Factory use OFF (OPEN) _
Never change the settings of S202 for bits 5 to 8 since each is set according to the characteristics of the unit
5, 6 : PLAYER/RECORDER PLAYER RECORDER
5: ON (CLOSE) OFF (OPEN) _
6: OFF (OPEN) ON (CLOSE) _
7 : J/UC ON (CLOSE) _
8 : 525/625 DNW-A220: OFF (OPEN) _
DNW-A220P: ON (CLOSE) _
SY-260 S201 1-8 : Factory use OFF (OPEN) _
*1, *2: Never change setting of the switches S101-1 and S101-2.
