DNW-A220
DNW-A220P
Ref.No. Switch name Description Factory setting
S1701-1 Y MUTE OFF: Normal mode OFF
ON: Luminance signal is muted
S1701-2 Factory use OFF
S1701-3 Factory use OFF
S1701-4 C MUTE OFF: Normal mode OFF
ON: Color difference signal is muted
S1701-5 COMB Selects whether a comb filter is turned on or off when OFF
the color difference signal has the significant line crawl which
the LCC cannot correct
OFF: Normal mode (Comb filter is turned off)
ON: Comb filter is turned on
S1701-6 Factory use OFF
S1701-7 Factory use OFF
S1701-8 Factory use OFF
S1801-1 D CLP OFF Turns on and off the digital clamp function OFF
Usually turn off this switch, and a DC difference between (Digital clamp ON)
B-Y and R-Y signals (if present) is corrected by the digital
clamp function
Turn on only to turn off the digital clamp for test
OFF: Normal mode (Digital clamp is turned on)
ON: Digital clamp is turned off
S1801-2 Factory use OFF
S1803-3 Factory use OFF
S1803-4 Factory use OFF
1-9. Settings for Internal Switches/Slit Lands
