Activating the Maintenance Mode
(1) Push the 9 S200 switch (on the SY-259/259A board).
(2) The mode screen in the maintenance mode is superimposed on the LCD monitor.
In a 1 sub LCD, “M0-TAPE MAINTEN” is displayed.
LCD Monitor Sub LCD
Activating the Maintenance Mode from Control Panel
The maintenance mode can be activated by the operation below when the S201-2 switch (on the SY-259/
259A board) is set to ON (upper).
(1) Push the 2 MENU button once.
(Execute the setup menu mode from the operation mode.)
(2) Push the 3 SET button while pressing the 4 CTL/TC/U-BIT button.
(Execute the maintenance mode from the setup menu mode.)
(3) The mode screen in the maintenance mode is displayed on the LCD monitor.
Terminating the Maintenance Mode
(1) Push the 2 MENU button several times to display the mode screen on the video monitor.
The selected mode No. and title are displayed in a time counter.
(2) Push the 2 MENU button again to terminate the maintenance mode.
3-1. Overview of Maintenance Mode
M0 -TAPE MAINTEN
MAINTENANCE MODE
M0 : TAPE MAINTENANCE
M2 : ERROR LOGGER
M3 : OTHERS
M4 : SETUP MAINTENANCE
*
To Next Page
