3-10
DNW-A220
DNW-A220P
SERVO ADJUST
A00:SERVO ADJUST
*
SERVO ADJUST
A000:A001-A003 ADJ.
A001:S REEL FG DUTY
A002:CAPSTAN FG DUTY
A003:CAPSTAN FRICTION
A004:CAPSTAN FREE SPEED
A005:RF SWITCHING POS.
A006:NV-RAM CONTROL
*
[SET]
[MENU]
A0 : SERVO ADJUST
This submode is used to adjust the servo system of a VTR.
For more details, refer to maintenance manual part 2 volume 1.
Title Page Description
A000 : A001-A003 ADJ. — Continuously executes the automatic adjustment menus (A001 to
A003).
A001 : S REEL FG DUTY — Automatically adjusts the duty ratio of an S reel FG.
A002 : CAPSTAN FG DUTY — Automatically adjusts the duty ratio of a capstan FG.
A003 : CAPSTAN FRICTION — Automatically adjusts the capstan friction.
A004 : CAPSTAN FREE SPEED — Automatically adjusts the capstan free speed.
A005 : RF SWITCHING POS. — Automatically adjusts the RF switching position.
A006 : NV-RAM CONTROL — Saves the adjustment data in a servo system.
3-2. TAPE Maintenance Mode (M0)
3-2-1. Overviews
