Sony DSC-S70 - Circuit Boards Location; Flexible Boards Location

2-8
2-11. FLEXIBLE BOARDS LOCATION
2-10. CIRCUIT BOARDS LOCATION
2-8 E
Flash unit
( )
SL-56
(SWITCH, LCD, JACK)
CD-282
(CCD IMAGER)
DD-141
DC/DC CONVERTER,
VIDEO, USB
( )
MS-54
FU/MEMORY
STICK
( )
SY-58
AUDIO, TG/AFE, LENS DRIVE, CAMERA, DISPLAY,
MEMORY CONTROL, SH DISP, HI CONTROL
DD-128
LCD DRIVE,
TIMING GENERATOR
( )
Inverter
transformer
unit
Indicator module
Cold cathode
fluorescent
tube
Control switch block
(Mode SW)
FP-027
FP-031
FP-029
FP-021
FP-028
FP-024
Control switch
block
(Zoom/Power SW)
