Sony DSC-S70 - Light Level Adjustment; Mixed Color Cancel Adjustment

5-18
6. Light Level Adjustment
Adjust the standard LV value.
Mode STILL
Subject Clear chart
(Color reproduction adjustment frame)
Measurement Point Displayed data of page: 1 (Note 2)
Measuring Instrument Adjusting remote commander
Adjustment Page F
Adjustment Address 26, 28
Specified Value AE level: 0FC0 to 1040
Note 1: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Note 2: The right four digits of the page: 1 displayed data of the
adjusting remote commander.
1:XX:XX
 Displayed data
Adjusting method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: 5, address: F1, and set data: FF.
3) Select page: D, address: 63, set data: 40, and press the PAUSE
button of the adjusting remote commander.
4) Perform “ Data setting during camera system adjustment”.
(Refer to page 5-13)
5) Select page: 6, address: 01, set data: 0D, and press the PAUSE
button. (The light level adjustment is performed and the ad-
justment data is stored in page: F, address: 26 and 28)
6) Select page: 6, address: 02, and check that the data is “01”.
7) Select page: 0, address: 03, and set data: 06.
8) Select page: 1, and check that the displayed data (Note 2)
satisfies the AE level specified value.
Processing after Completing Adjustments:
1) Select page: 0, address: 03, and set data: 00.
2) Select page: 6, address: 01, set data: 00, and press the PAUSE
button of the adjusting remote commander.
3) Select page: 5, address: F1, and set data: 00.
4) Select page: D, address: 63, set data: 00, and press the PAUSE
button.
5) Release the data setting performed at step 4).
(Refer to page 5-13)
6) Select page: 0, address: 01, and set data: 00.
7. Mixed Color Cancel Adjustment
To perform mixed color cancel adjustment based on data of each
color in color bar.
Mode STILL
Subject Color bar chart
(Color reproduction adjustment frame)
Adjustment Page F
Adjustment Address A0 to A3
Note 1: Perform “Light Level Adjustment” before this
adjustment.
Note 2: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Adjusting method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: 5, address: F1, and set data: FF.
3) Select page: D, address: 63, set data: 40, and press the PAUSE
button of the adjusting remote commander.
4) Perform “ Data setting during camera system adjustment”.
(Refer to page 5-13)
5) Select page: 6, address: 01, set data: D7, and press the PAUSE
button.
6) Select page: 6, address: 01, set data: D5, and press the PAUSE
button. (The mixed color adjustment is performed and the
adjustment data is stored in page: F, address: A0 to A3)
7) Select page: 6, address: 02, and check that the data is “01”.
Processing after Completing Adjustments:
1) Select page: 6, address: 01, set data: 00, and press the PAUSE
button of the adjusting remote commander.
2) Select page: 5, address: F1, and set data: 00.
3) Select page: D, address: 63, set data: 00, and press the PAUSE
button.
4) Release the data setting performed at step 4).
(Refer to page 5-13)
5) Select page: 0, address: 01, and set data: 00.
