NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
6-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
CD-282 DD-141
• Abbreviation
AUS : Australian model
CN : Chinese model
CND : Canadian model
HK : Hong Kong model
J : Japanese model
JE : Tourist model
KR : Korea model
(Note) Be sure to read “Note on the CCD Imager
Replacement” on page 4-8 when changing
the CCD imager
A-7074-362-A CD-282 BOARD, COMPLETE
***********************
(Ref.No.:2, 000 Series)
(IC401 is not included in this complete board)
< CAPACITOR >
C401 1-113-985-11 TANTAL. CHIP 10uF 20% 20V
C402 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C403 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C404 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C405 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C406 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C407 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C408 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C409 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 16V
C412 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C413 1-125-827-91 CERAMIC CHIP 1uF 10% 25V
C414 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< DIODE >
D401 8-719-073-01 DIODE MA111- (K8).S0
< INDUCTOR >
FB401 1-414-228-11 INDUCTOR CHIP 0uH
< IC >
IC401 A-7031-084-A IC CCD BLOCK ASSY (CCD IMAGER)
< COIL >
L401 1-469-058-11 INDUCTOR CHIP 22uH
< TRANSISTOR >
Q401 8-729-037-74 TRANSISTOR UN9213J- (K8).SO
Q402 8-729-117-73 TRANSISTOR 2SC4178-F13F14-T1
< RESISTOR >
R401 1-218-990-11 SHORT 0
R402 1-218-990-11 SHORT 0
R403 1-218-958-11 RES-CHIP 2.7K 5% 1/16W
R404 1-218-989-11 RES-CHIP 1M 5% 1/16W
R406 1-218-946-11 RES-CHIP 270 5% 1/16W
R407 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R408 1-218-990-11 SHORT 0
R409 1-218-977-11 RES-CHIP 100K 5% 1/16W
R412 1-218-990-11 SHORT 0
< THERMISTOR >
TH401 1-809-361-21 THERMISTOR
PPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
A-7074-360-A DD-141 (70) BOARD, COMPLETE
***************************
(Ref.No.:1, 000 Series)
< CAPACITOR >
C001 1-164-880-11 CERAMIC CHIP 180PF 5% 16V
C002 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C003 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C004 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C005 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C007 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C008 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C009 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C010 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C013 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C014 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C015 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C016 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C017 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C018 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C019 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C020 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C021 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C022 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C023 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C024 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C025 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C026 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C027 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C028 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
To Next Page
