4. Switch Check (2)
Page 2 Address 54 to 57
Using method:
1) Select page: 2, addresses: 54 to 57.
2) By discriminating the dispaly data, the pressed key can be
discriminated.
Address
Data
00 to 14 15 to 33 3C to 64 65 to 91 92 to BD BE to E9 EA to FF
55
CONTROL DOWN CONTROL UP DISPLAY VOLUME/ VOLUME/
(KEY AD1) (SL-56 board) (SL-56 board) (SL-56 board) PROGRAM AE+ PROGRAM AE–
(IC404 uk) (S151) (S151) (S153) (SL-56 board) (SL-56 board)
(S155) (S157)
56
CONTROL RIGHT CONTROL LEFT CONTROL SET FLASH FOCUS COLOR LCD
(KEY AD2) (SL-56 board) (SL-56 board) (SL-56 board) (SL-56 board) (SL-56 board) ON/OFF
(IC404 i;) (S151) (S151) (S151) (S154) (S156) (SL-56 board)
(S158)
57 PROGRAM AE
(KEY AD3) (SL-56 board)
(IC404 ia) (S152)
5. LED Check
Using method:
1) Select page: 2, address: 06, and set data: 01.
2) Check that all LED except for the ACCESS LED are lit.
3) Select page: 2, address: 06, and set data: 00.
6. LCD Check
Using method:
1) Select page: 2, address: 05, and set data: 02.
2) Check that all LED are lit and all segments of LCD (display
window) are lit.
3) Select page: 2, address: 05, and set data: 00.
Page 2 Address 06 Data 02
