105
Specifications
Imaging system/optical system
Pickup device
1
/
2
-inch CCD, interline transfer
type
Effective picture elements 768 (horizontal) × 494 (vertical)
Lens mount
1
/
2
-inch bayonet type
Video system
Synchronization Internal/external (VBS)
synchronization, automatic
switching
Signal format NTSC standard format
(EIA standard)
Horizontal scanning 525 lines, 2:1 interlace
Scanning frequency Horizontal: 15.732 kHz
Vertical: 59.94 Hz
Functions/performance
Horizontal resolution 750 TV lines
Sensitivity 2,000 lux (F9.5, 3200K)
Signal-to-noise ratio 60 dB
Gain control • Automatic
• Manual: 0 – 18 dB
in units of 1 dB
• ISO display
White balancing • Automatic
• Manual: Red gain and green
gain adjustable individually
•ATW
Linear matrix On/off switchable
Electronic shutter speed Adjustable in the range of
1/10,000 to about 8.5 seconds
(Usable with CCD IRIS)
Gamma compensation On/off switchable
Charge accumulation mode
Switchable between field and
frame modes
