61
VF Menu List
Chapter 4 Menu Configuration and Detailed Settings
<SDI2 Look>
SDI2 look
settings
Select Color/1D LUT S-Log2/S-Gamut, Color/
1D LUT
Sets the look type of the video output
image on the SDI OUT2 connector.
S-Log2/S-Gamut: Outputs images in S-
Log2 or S-Gamut.
Color/1D LUT: Outputs images with the
specified Color and 1D LUT settings.
Color ITU-R BT.709 S-Gamut, F900,
ITU-R BT.709
Sets the color reproduction of the video
output image on the SDI OUT2
connector.
S-Gamut: Wide color space comparable
to film cameras.
F900: Color space equivalent to
conventional cameras.
ITU-R BT.709: Color space equivalent to
ITU-R BT.709.
1D LUT 709(800%) 709(800%), S-Log2,
HG8009G40, HG8009G33,
[User1], [User2], [User3],
[User4], [User5] to [User100]
Selects the 1D LUT for the video output
on the SDI OUT2 connector.
709(800%): Signal extending the
dynamic range up to 800% based on
ITU-R709.
S-Log2: Non-adjustable signal for
required post-production processing.
Up to 1300% input light level can be
reproduced.
HG8009G40: Signal using hypergamma
with 800% dynamic range, 109%
white limit, and 40% video output for
18% gray card.
HG8009G33: Signal using hypergamma
with 800% dynamic range, 109%
white limit, and 33% video output for
18% gray card.
[User1] to [User100]: Imported, user-
defined LUT signals.
<VF/HD-Y
Source>
Select SDI-OUT2 SDI-OUT1, SDI-OUT2 Switches the output source for the video
signals output on the VF and HD-Y
connectors.
<VF/SDI
Signal>
Output signal
settings
Effective Area 4096:2160 4096:2160, 3840:2160,
Anamorphic Unsqueeze x2
Selects the video for output (F65RAW,
F65RAW-HFR only).
Color Color Color, R, G, B Selects the output RGB channels.
Scan Type (Over
30p)
Interlace Interlace, Frame Drop Selects whether to output video with
reduced distortion of fast-moving
subjects when Frame Rate is set to 50p
or higher.
Image Invert
Select
Off Off, Vertical, Horizontal,
Vertical & Horizontal
Selects the type of image inversion.
Off: No image inversion
Vertical: Top to bottom
Horizontal: Left to right
Vertical & Horizontal: Top to bottom and
left to right
Page Configuration
item
Default Settings Remarks
