Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-AZ33D
104
R953 1-216-833-11 METAL CHIP 10K 5% 1/10W
R961 1-216-820-11 METAL CHIP 820 5% 1/10W
R962 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R963 1-219-706-11 RES-CHIP 0.1 1% 1W
R964 1-216-815-11 METAL CHIP 330 5% 1/10W
R965 1-218-291-11 METAL CHIP 16K 5% 1/10W
R966 1-216-809-11 METAL CHIP 100 5% 1/10W
R968 1-216-817-11 METAL CHIP 470 5% 1/10W
R981 1-216-820-11 METAL CHIP 820 5% 1/10W
R982 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R988 1-216-817-11 METAL CHIP 470 5% 1/10W
< TRANSFORMER >
T301 1-433-372-31 TRANSFORMER, BIAS OSCILLATION
< VIBRATOR >
X401 1-760-252-12 VIBRATOR, CRYSTAL (32.768kHz)
X402 1-760-489-11 VIBRATOR, CERAMIC (5MHz)
************************************************************
MS-214 BOARD
************
< CONNECTOR >
CN001 1-815-569-11 CONNECTOR, FFC/FPC 7P
< SWITCH >
S001 1-762-951-13 SWITCH, PUSH (DISC IN/OUT)
S002 1-762-951-13 SWITCH, PUSH (CHUCKING)
S003 1-762-951-13 SWITCH, PUSH (TRIGGER)
************************************************************
A-1249-517-A S-MASTER BOARD, COMPLETE
*************************
< CAPACITOR >
C500 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C504 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C505 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C506 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C507 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C508 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C509 1-104-658-91 ELECT 100uF 20% 10V
C510 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C511 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C512 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C513 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C514 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C515 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C519 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C531 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C532 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C533 1-104-662-91 ELECT 22uF 20% 25V
C534 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C535 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C536 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C537 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C538 1-137-807-31 ELECT 100uF 20% 50V
C544 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C545 1-137-807-31 ELECT 100uF 20% 50V
C547 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C548 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C549 1-126-953-11 ELECT 2200uF 20% 35V
C551 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C552 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C553 1-104-662-91 ELECT 22uF 20% 25V
C554 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C555 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C556 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C557 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C558 1-137-807-31 ELECT 100uF 20% 50V
C564 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C565 1-137-807-31 ELECT 100uF 20% 50V
C567 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C568 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C569 1-126-953-11 ELECT 2200uF 20% 35V
C580 1-137-198-81 FILM 1uF 5% 50V
C581 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C582 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C583 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C584 1-137-198-81 FILM 1uF 5% 50V
C585 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C586 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C587 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C590 1-137-198-81 FILM 1uF 5% 50V
C591 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C592 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C593 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C594 1-137-198-81 FILM 1uF 5% 50V
C595 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C596 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C597 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C730 1-126-961-11 ELECT 2.2uF 20% 50V
C793 1-126-957-11 ELECT 0.22uF 20% 50V
C800 1-124-248-00 ELECT 22uF 20% 25V
C801 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C802 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C803 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C804 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C805 1-104-658-91 ELECT 100uF 20% 10V
C806 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C810 1-104-658-91 ELECT 100uF 20% 10V
C811 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C824 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C830 1-126-964-11 ELECT 10uF 20% 50V
C850 1-117-370-11 CERAMIC CHIP 10uF 10V
C855 1-117-370-11 CERAMIC CHIP 10uF 10V
C871 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C872 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C874 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C876 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C877 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C878 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C879 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C880 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C881 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C882 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C883 1-126-925-91 ELECT 470uF 20% 10V
C884 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C885 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C886 1-126-935-11 ELECT 470uF 20% 16V
MAIN MS-214 S-MASTER
