90
HCD-AZ33D
SECTION 9
ELECTRICAL PARTS LIST
A-1249-519-A ADC BOARD, COMPLETE
********************
< CAPACITOR >
C23 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C24 1-104-658-91 ELECT 100uF 20% 10V
C25 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C26 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C27 1-126-963-11 ELECT 4.7uF 20% 50V
C28 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C29 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C32 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C40 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C41 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C42 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C50 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C51 1-126-964-11 ELECT 10uF 20% 50V
C53 1-104-658-91 ELECT 100uF 20% 10V
C54 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C55 1-126-964-11 ELECT 10uF 20% 50V
C56 1-135-834-91 CERAMIC CHIP 2.2uF 6.3V
C58 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C59 1-126-960-11 ELECT 1uF 20% 50V
C60 1-126-960-11 ELECT 1uF 20% 50V
C81 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C90 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C91 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
< CONNECTOR >
* CN1 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
CN3 1-564-704-41 PIN, CONNECTOR (SMALL TYPE) 2P
< DIODE >
D11 6-500-848-01 DIODE MC2840-T112-1
D13 6-501-579-01 DIODE MC2837
D51 6-500-335-01 DIODE MC2838-T112-1
< EARTH TERMINAL >
* EP1 1-537-738-21 TERMINAL, EARTH
* EP2 1-537-738-21 TERMINAL, EARTH
< FILTER >
FL1 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL2 1-234-494-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC2 8-759-641-26 IC NJM2391DL1-33 (TE1)
IC3 8-759-242-70 IC TC7WU04F
IC11 6-710-840-01 IC AK5358AET-E2
< RESISTOR >
JR1 1-216-864-11 SHORT CHIP 0
JR51 1-216-806-11 METAL CHIP 56 5% 1/10W
JR52 1-216-809-11 METAL CHIP 100 5% 1/10W
< COIL >
L1 1-412-939-11 INDUCTOR 1uH
L2 1-412-951-11 INDUCTOR 10uH
L3 1-412-951-11 INDUCTOR 10uH
< RESISTOR >
R25 1-216-809-11 METAL CHIP 100 5% 1/10W
R27 1-216-845-11 METAL CHIP 100K 5% 1/10W
R29 1-216-809-11 METAL CHIP 100 5% 1/10W
R31 1-216-845-11 METAL CHIP 100K 5% 1/10W
R36 1-216-864-11 SHORT CHIP 0
R38 1-216-864-11 SHORT CHIP 0
R40 1-216-821-11 METAL CHIP 1K 5% 1/10W
R41 1-216-857-11 METAL CHIP 1M 5% 1/10W
R50 1-216-864-11 SHORT CHIP 0
R51 1-216-864-11 SHORT CHIP 0
R52 1-216-809-11 METAL CHIP 100 5% 1/10W
R53 1-216-809-11 METAL CHIP 100 5% 1/10W
R54 1-216-864-11 SHORT CHIP 0
R58 1-216-809-11 METAL CHIP 100 5% 1/10W
R59 1-216-809-11 METAL CHIP 100 5% 1/10W
R67 1-216-809-11 METAL CHIP 100 5% 1/10W
< VIBRATOR >
X1 1-814-042-11 VIBRATOR, CRYSTAL (12.288MHz)
************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
ADC
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AUS : Australian model
E3 : 240V AC area in E model
E12 : 220V – 240V AC area in E model
E13 : 220V – 230V AC area in E model
E15 : Iranian model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
PH : Philippines model
SP : Singapore model
TH : Thai model
