Sony HCD-AZ33D - DMB17 Board; Front Panel Block

HCD-AZ33D
15
3-9. DMB17 BOARD
3-10. FRONT PANEL BLOCK
 four screws
(BVTP3 × 8)
 DMB17 board
 connector
(CN401)
 flexible flat cable (19 core)
(CN302)
 flexible flat cable (15 core)
(CN106)
 flexible flat cable (13 core)
(CN303)
 flexible flat cable (5 core)
(CN111)
 three screws
(BVTP3 × 8)
 connector (CN503)
 front panel block
