Sony HCD-AZ33D - Motor (Pulley) Assy (Loading) (M001); Holder (BU) Assy

HCD-AZ33D
17
3-13. MOTOR (PULLEY) ASSY (LOADING) (M001)
3-14. HOLDER (BU) ASSY
 Remove two solders.
 two screws
(B 2.6 × 8)
 MS-214 board
 motor (pully) assy (loading)
(M001)
 belt (MOT)
 screw
(B 2.6 × 8)
 lever (CL UP2)
 holder (BU) assy
 floating screw
(PTPWH M2.6)
 floating screw
(PTPWH M2.6)
 LHL support
 two screws
(B 2 × 6)
