HCD-AZ33D
77
Pin No. Pin Name I/O Description
53 P_SM_NSP_MUTING O NSP muting control signal output to the stream processor
54 - - Not used
55 P_SM_CD_DET I Shut down signal input from the digital power amplifi er "L": shut down
56 P_SM_DRV_RST O Reset signal output to the digital power amplifi er "L": reset
57
"P_SM_SOFT
_MUTING"
O Soft muting control signal output to the stream processor
58 P_SM_CS1 O Chip select signal output to the stream processor (for front L-ch and R-ch)
59 P_SM_CS2 O Chip select signal output to the stream processor (for center and sub woofer) Not used
60 P_SM_CS3 O Chip select signal output to the stream processor (for surround L-ch and R-ch) Not used
61 HP_MUTING O Headphone muting on/off control signal output terminal "L": muting on
62 VCC - Power supply terminal (+3.3V)
63 P_HEADPHONE _IN I Headphone detection signal input terminal "H": headphone insert
64 VSS - Ground terminal
65 P_MIC_IN I Microphone detection signal input terminal "H": microphone insert
66 P_LINE_MUTING O Line muting on/off control signal output terminal "L": muting on
67 TC BIAS O Recording bias on/off control signal output terminal "H": bias on
68 TC PB/REC O Recording/playback selection signal output terminal "L": recording, "H": playback
69 TC REC MUTE O Recording muting on/off control signal output terminal "L": muting on
70 TC LINE MUTE O Playback muting on/off control signal output terminal "H": muting on
71 P_AMPIC_DATA O Serial data output to the electrical volume
72 P_AMPIC_CLK O Serial data transfer clock signal output to the electrical volume
73 P_POWER_KEY I Key wake up signal input terminal
74 P_DISP_KEY I Key wake up signal input terminal
75 BT RESET O Reset signal output terminal for bluetooth section Not used
76 P_LINK_SW O Audio signal (for surround L-ch and R-ch) selection signal output terminal Not used
77 P_A_MUTE O CD, DVD and USB input analog muting on/off control signal output terminal "L": muting on
78 TC CAPM+ O Capstan/reel motor drive signal output terminal "L": FWD/stop, "H": REV
79 TC TRGM+ O Trigger plunger drive signal output terminal "H": plunger on
80 - - Not used
81, 82 KEY IN_2, KEY IN_0 I Touch sensor signal input from the touch sensor driver
83 TS-MODE O Mode signal output to the touch sensor driver
84 TS-CS O Chip select signal output to the touch sensor driver
85 TS-CLK O Clock signal output to the touch sensor driver
86 TS-POWER O Power supply on/off control signal output terminal for touch sensor section "H": power on
87 KEY IN_1 I Touch sensor signal input from the touch sensor driver
88 P_DVD_3.3V_MNT I Power supply (+3.3V) monitor terminal for DVD section
89 P_VACS I Sound level signal for VACS input from the electrical volume
90 TC SHUT I Tape reel rotating detection signal input from the tape mechanism deck block
91 TC HALF/REC I
Cassette detection signal input from the tape mechanism deck block "L": cassette insert
Recording-proof (forward and reverse direction) detection signal input from the tape mecha-
nism deck block "L": recording possible
92 SPEC-IN I Destination setting input terminal (A/D input)
93 MODEL-IN I Model setting input terminal (A/D input)
94, 95 KEY_2, KEY_1 I Key input terminal (A/D input)
96 AVSS - Ground terminal (analog system)
97 BT LED/DMP DET I Digital media port adaptor detection signal input terminal "H": adaptor insert
98 VREF I Reference voltage (+3.3V) input terminal (analog system)
99 AVCC - Power supply terminal (+3.3V) (analog system)
100 STANBY LED O LED drive signal output terminal of the standby indicator "H": LED on
