Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-AZ33D
92
C1503 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C2501 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3612 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3701 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3702 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3707 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3708 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3711 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C3712 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3713 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C3714 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C3721 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C3722 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3723 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C3724 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C3771 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C3772 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3773 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C3774 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C3781 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C3782 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3783 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C3784 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C3801 1-104-655-91 ELECT 470uF 20% 6.3V
C3802 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C3803 1-104-658-91 ELECT 100uF 20% 10V
C3804 1-126-947-11 ELECT 47uF 20% 35V
C3805 1-126-947-11 ELECT 47uF 20% 35V
< CONNECTOR >
CN101 1-815-763-32 CONNECTOR, FFC/FPC 24P
* CN105 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN106 1-779-283-11 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
CN111 1-784-766-11 CONNECTOR, FFC 5P
* CN201 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN203 1-779-275-11 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
CN302 1-779-287-11 CONNECTOR, FFC (LIF (NON-ZIF)) 19P
CN303 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN401 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
< DIODE >
D3501 8-719-404-50 DIODE MA111-TX
D3502 8-719-404-50 DIODE MA111-TX
< EARTH TERMINAL >
ET001 1-537-771-21 TERMINAL BOARD, GROUND
ET002 1-537-771-21 TERMINAL BOARD, GROUND
ET003 1-537-771-21 TERMINAL BOARD, GROUND
< FERRITE BEAD/JUMPER RESISTOR >
FB104 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB105 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB106 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB107 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB108 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB110 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB111 1-414-226-21 INDUCTOR, FERRITE BEAD
FB112 1-414-226-21 INDUCTOR, FERRITE BEAD
FB113 1-414-226-21 INDUCTOR, FERRITE BEAD
FB114 1-414-226-21 INDUCTOR, FERRITE BEAD
FB115 1-414-226-21 INDUCTOR, FERRITE BEAD
FB401 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB402 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB403 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB404 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB405 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB406 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1101 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1103 1-216-295-91 SHORT CHIP 0
< FILTER >
FL401 1-234-177-21 FILTER, CHIP EMI
FL402 1-233-893-21 FILTER, CHIP EMI
FL403 1-234-177-21 FILTER, CHIP EMI
< IC >
IC101 6-807-511-01 IC MX29LV320CBTC70-SBA2-0701CE
(EXCEPT PH, SP, TH)
IC101 6-807-512-01 IC MX29LV320CBTC70-SBA2-0701GA
(PH, SP, TH)
IC102 6-710-093-01 IC CXD9889R
IC103 (Not supplied) IC BR24L64F-WE2
IC104 6-709-737-01 IC M12L64164A-7T (G)
IC105 6-702-302-01 IC TK11133CSCL-G
IC107 6-702-302-01 IC TK11133CSCL-G
IC110 6-707-739-01 IC MM1661JTRE
IC201 6-704-524-01 IC FAN8036L
IC301 6-704-222-01 IC AK4358VQ-L
IC3711 8-759-359-49 IC NJM3414AV (TE2)
IC3771 8-759-359-49 IC NJM3414AV (TE2)
< TRANSISTOR >
Q101 6-550-008-01 FET UM6K1N-TN
Q102 6-550-653-01 TRANSISTOR QST8TR
Q103 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q2001 8-729-045-62 FET 2SK2158-T2B
Q3801 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR/FERRITE BEAD >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R102 1-216-295-91 SHORT CHIP 0
R103 1-216-864-11 SHORT CHIP 0
R104 1-216-864-11 SHORT CHIP 0
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
R106 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-857-11 METAL CHIP 1M 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-841-11 METAL CHIP 47K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R113 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R116 1-216-821-11 METAL CHIP 1K 5% 1/10W
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R118 1-216-801-11 METAL CHIP 22 5% 1/10W
R120 1-216-801-11 METAL CHIP 22 5% 1/10W
R121 1-216-801-11 METAL CHIP 22 5% 1/10W
R123 1-216-864-11 SHORT CHIP 0
DMB17
Ver. 1.2
Note: When IC103 on the DMB17 board is damaged, exchange
the new DMB17 board for the DMB17 board which IC103
damaged.
To Next Page
