Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-AZ33D
9797
< VARIABLE RESISTOR >
RV1061 1-223-983-11 RES, VAR, CARBON 50K (ECHO LEVEL)
RV1062 1-223-983-11 RES, VAR, CARBON 50K (MIC LEVEL)
************************************************************
KEY BOARD
**********
< CAPACITOR >
C401 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
< CONNECTOR >
CN402 1-564-723-11 PIN, CONNECTOR (SMALL TYPE) 7P
< LED >
D402 6-501-483-01 LED SLR-325VCT31P (STANDBY)
< IC >
IC401 6-711-556-01 IC NJL24H400B-SA
< RESISTOR >
R401 1-216-821-11 METAL
CHIP 1K 5% 1/10W
R402 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R403 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R404 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R405 1-216-821-11 METAL CHIP 1K 5% 1/10W
R406 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R407 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R408 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R409 1-216-821-11 METAL CHIP 1K 5% 1/10W
R412 1-216-833-11 METAL CHIP 10K 5% 1/10W
R413 1-216-833-11 METAL CHIP 10K 5% 1/10W
R414 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S400 1-762-875-21 SWITCH, KEYBOARD (I/1)
S401 1-762-875-21 SWITCH, KEYBOARD (PROGRESSIVE)
S402 1-762-875-21 SWITCH, KEYBOARD (SOUND FIELD)
S403 1-762-875-21 SWITCH, KEYBOARD (EQ EDIT)
S404 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
S405 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S406 1-762-875-21 SWITCH, KEYBOARD (DSGX)
S407 1-762-875-21 SWITCH, KEYBOARD (PRESET EQ)
S408 1-762-875-21 SWITCH, KEYBOARD (DIRECTION)
S409 1-762-875-21 SWITCH, KEYBOARD (z START)
************************************************************
A-1249-463-A MAIN BOARD, COMPLETE (E3, E15)
A-1249-465-A MAIN BOARD, COMPLETE (PH, SP, TH)
A-1249-467-A MAIN BOARD, COMPLETE (E12)
A-1249-468-A MAIN BOARD, COMPLETE (E13)
A-1249-469-A MAIN BOARD, COMPLETE (AUS)
A-1309-123-A MAIN BOARD, COMPLETE (AEP)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C10 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C29 1-126-964-11 ELECT 10uF 20% 50V
C30 1-126-964-11 ELECT 10uF 20% 50V
C31 1-124-261-00 ELECT 10uF 20% 50V
C32 1-124-261-00 ELECT 10uF 20% 50V
C73 1-126-963-11 ELECT 4.7uF 20% 50V
C74 1-126-963-11 ELECT 4.7uF 20% 50V
C100 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C101 1-126-964-11 ELECT 10uF 20% 50V
C102 1-126-964-11 ELECT 10uF 20% 50V
C103 1-126-964-11 ELECT 10uF 20% 50V
C104 1-126-964-11 ELECT 10uF 20% 50V
C105 1-136-497-81 FILM 0.1uF 5% 50V
C106 1-126-964-11 ELECT 10uF 20% 50V
C107 1-104-509-11 CERAMIC CHIP 0.018uF 10% 16V
C108 1-104-509-11 CERAMIC CHIP 0.018uF 10% 16V
C109 1-126-965-91 ELECT 22uF 20% 50V
C110 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C111 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C112 1-126-964-11 ELECT 10uF 20% 50V
C113 1-137-195-11 FILM 0.56uF 5% 50V
C114 1-137-194-81 FILM 0.47uF 5% 50V
C115 1-126-964-11 ELECT 10uF 20% 50V
C116 1-126-964-11 ELECT 10uF 20% 50V
C117 1-126-960-11 ELECT 1uF 20% 50V
C118 1-137-150-11 FILM 0.01uF 5% 100V
C119 1-126-964-11 ELECT 10uF 20% 50V
C120 1-126-964-11 ELECT 10uF 20% 50V
C123 1-163-077-00 CERAMIC CHIP 0.1uF 50V
C124 1-104-658-91 ELECT 100uF 20% 10V
C125 1-104-658-91 ELECT 100uF 20% 10V
C126 1-104-658-91 ELECT 100uF 20% 10V
C127 1-104-658-91 ELECT 100uF 20% 10V
C128 1-126-964-11 ELECT 10uF 20% 50V
C129 1-137-194-81 FILM 0.47uF 5% 50V
C130 1-137-374-11 MYLAR 0.047uF 5% 50V
C131 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C135 1-126-960-11 ELECT 1uF 20% 50V
C136 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C138 1-126-964-11 ELECT 10uF 20% 50V
C139 1-126-964-11 ELECT 10uF 20% 50V
C140 1-126-960-11 ELECT 1uF 20% 50V
C141 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C142 1-126-964-11 ELECT 10uF 20% 50V
C143 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C144 1-126-964-11 ELECT 10uF 20% 50V
C146 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C147 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C150 1-163-077-00 CERAMIC CHIP 0.1uF 50V
C151 1-126-964-11 ELECT 10uF 20% 50V
C152 1-126-964-11 ELECT 10uF 20% 50V
C154 1-126-964-11 ELECT 10uF 20% 50V
C155 1-136-497-81 FILM 0.1uF 5% 50V
C156 1-126-964-11 ELECT 10uF 20% 50V
C157 1-104-509-11 CERAMIC CHIP 0.018uF 10% 16V
C158 1-104-509-11 CERAMIC CHIP 0.018uF 10% 16V
C159 1-126-965-91 ELECT 22uF 20% 50V
C160 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C161 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C162 1-126-964-11 ELECT 10uF 20% 50V
C163 1-137-195-11 FILM 0.56uF 5% 50V
C164 1-137-194-81 FILM 0.47uF 5% 50V
HP MIC KEY MAIN
