86
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SECTION 8
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
When indicating parts by reference number,
please include the board name.
• Abbreviation
HK : HongKong model
A-4426-951-A AMP BOARD, COMPLETE
********************
1-533-293-11 FUSE HOLDER
< CAPACITOR >
C801 1-126-048-81 ELECT 10uF 20.00% 50V
C802 1-162-286-31 CERAMIC 220PF 10% 50V
C803 1-126-964-11 ELECT 10uF 20.00% 50V
C804 1-162-288-31 CERAMIC 330PF 10% 50V
C805 1-126-051-11 ELECT 47uF 20.00% 50V
C806 1-126-051-11 ELECT 47uF 20.00% 50V
C807 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C808 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C821 1-126-965-11 ELECT 22uF 20.00% 50V
C822 1-126-052-11 ELECT 100uF 20.00% 35V
C823 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C824 1-164-159-11 CERAMIC 0.1uF 50V
C831 1-126-052-11 ELECT 100uF 20.00% 35V
C832 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C833 1-126-042-11 ELECT 3300uF 20.00% 35V
C834 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C835 1-126-042-11 ELECT 3300uF 20.00% 35V
C836 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C841 1-126-960-11 ELECT 1uF 20.00% 50V
C851 1-126-048-81 ELECT 10uF 20.00% 50V
C852 1-162-286-31 CERAMIC 220PF 10% 50V
C853 1-126-964-11 ELECT 10uF 20.00% 50V
C854 1-162-288-31 CERAMIC 330PF 10% 50V
C855 1-126-051-11 ELECT 47uF 20.00% 50V
C856 1-126-051-11 ELECT 47uF 20.00% 50V
C857 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C858 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C871 1-126-933-11 ELECT 100uF 20.00% 16V
C881 1-126-959-11 ELECT 0.47uF 20.00% 50V
C882 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C883 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C884 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C885 1-136-495-11 MYLAR 0.068uF 5.00% 50V
< CONNECTOR >
* CN802 1-564-506-11 PLUG, CONNECTOR 3P
* CN882 1-564-515-11 PLUG, CONNECTOR 12P
< DIODE >
D801 8-719-911-19 DIODE 1SS133T-72
D802 8-719-911-19 DIODE 1SS133T-72
D832 8-719-028-23 DIODE D3SBA20-4101
D851 8-719-911-19 DIODE 1SS133T-72
D852 8-719-911-19 DIODE 1SS133T-72
D881 8-719-911-19 DIODE 1SS133T-72
D882 8-719-911-19 DIODE 1SS133T-72
< FUSE >
0 F801 1-532-504-31 FUSE 4A/125V
0 F802 1-532-504-31 FUSE 4A/125V
< IC >
IC801 8-749-920-13 IC STK4132MK2
< COIL >
L881 1-420-872-00 COIL, AIR-CORE
L882 1-420-872-00 COIL, AIR-CORE
< TRANSISTOR >
Q801 8-729-044-08 TRANSISTOR 2SD1915(F)-T(TA).SO
Q802 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q841 8-729-900-80 TRANSISTOR UN4211-TA
Q851 8-729-044-08 TRANSISTOR 2SD1915(F)-T(TA).SO
Q852 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q871 8-729-119-76 TRANSISTOR 2SA1115TP-EF
Q872 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q873 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q881 8-729-111-29 TRANSISTOR 2SD1616-TP-K
< RESISTOR >
R801 1-249-421-11 CARBON 2.2K 5% 1/4W F
R802 1-249-429-11 CARBON 10K 5% 1/4W
R803 1-249-437-11 CARBON 47K 5% 1/4W
R804 1-249-437-11 CARBON 47K 5% 1/4W
R805 1-249-417-11 CARBON 1K 5% 1/4W F
R806 1-249-437-11 CARBON 47K 5% 1/4W
R807 1-260-103-11 CARBON 2.2K 5% 1/2W
R808 1-260-103-11 CARBON 2.2K 5% 1/2W
0 R809 1-217-151-00 METAL 0.22 10% 2W
R810 1-249-417-11 CARBON 1K 5% 1/4W F
R811 1-249-431-11 CARBON 15K 5% 1/4W
R812 1-260-076-11 CARBON 10 5% 1/2W
0 R820 1-219-153-11 FUSIBLE 10 5% 1/4W
0 R821 1-212-881-11 FUSIBLE 100 5% 1/4W
R822 1-260-099-11 CARBON 1K 5% 1/2W
R823 1-260-099-11 CARBON 1K 5% 1/2W
R824 1-249-441-11 CARBON 100K 5% 1/4W
R825 1-249-433-11 CARBON 22K 5% 1/4W
0 R831 1-212-881-11 FUSIBLE 100 5% 1/4W
R841 1-249-437-11 CARBON 47K 5% 1/4W
AMP
To Next Page
