Sony HCD-J3MD - Page 89

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
89
1-674-336-11 LOADING BOARD
**************
< CONNECTOR >
* CN151 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S1 1-771-799-11 SWITCH, LEVER (SLIDE) (LOADING SWITCH)
************************************************************
A-4428-956-A MAIN BOARD, COMPLETE (HK)
*************************
A-4473-393-A MAIN BOARD, COMPLETE (EXCEPT HK)
********************************
7-685-871-01 SCREW+BVTT 3X6 (S)
< CAPACITOR >
C113 1-126-964-11 ELECT 10uF 20.00% 50V
C132 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V (HK)
C132 1-163-038-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT HK)
C142 1-126-933-11 ELECT 100uF 20.00% 16V
C143 1-126-933-11 ELECT 100uF 20.00% 16V
C144 1-126-964-11 ELECT 10uF 20.00% 50V
C163 1-126-964-11 ELECT 10uF 20.00% 50V
C194 1-126-964-11 ELECT 10uF 20.00% 50V
C201 1-128-835-91 ELECT 1000uF 20% 10V
C202 1-128-834-11 ELECT 470uF 20% 10V
C203 1-128-834-11 ELECT 470uF 20% 10V
C204 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C205 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C206 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C207 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V (HK)
C211 1-164-159-11 CERAMIC 0.1uF 50V
C213 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C223 1-126-964-11 ELECT 10uF 20.00% 50V
C232 1-126-933-11 ELECT 100uF 20.00% 16V
(EXCEPT HK)
C237 1-126-961-11 ELECT 2.2uF 20.00% 50V
(EXCEPT HK)
C238 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
(EXCEPT HK)
C240 1-163-006-11 CERAMIC CHIP 560PF 10.00% 50V
(EXCEPT HK)
C241 1-163-239-11 CERAMIC CHIP 33PF 5.00% 50V
(EXCEPT HK)
C242 1-163-239-11 CERAMIC CHIP 33PF 5.00% 50V
(EXCEPT HK)
C244 1-126-933-11 ELECT 100uF 20.00% 16V
(EXCEPT HK)
C302 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C303 1-119-821-11 ELECT MELF 2.2uF 20% 50V
C304 1-130-475-00 MYLAR 0.0022uF 5% 50V
C305 1-126-045-11 ELECT 2.2uF 20.00% 50V
C306 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C307 1-119-821-11 ELECT MELF 2.2uF 20% 50V
C308 1-119-821-11 ELECT MELF 2.2uF 20% 50V
C309 1-162-282-31 CERAMIC 100PF 10% 50V
C310 1-119-821-11 ELECT MELF 2.2uF 20% 50V
C311 1-126-048-81 ELECT 10uF 20.00% 50V
C312 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C313 1-126-957-11 ELECT 0.22uF 20.00% 50V
C314 1-130-473-00 MYLAR 0.0015uF 5% 50V
C315 1-126-048-81 ELECT 10uF 20.00% 50V
C316 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C317 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C322 1-126-964-11 ELECT 10uF 20.00% 50V
C323 1-126-048-81 ELECT 10uF 20.00% 50V
C324 1-124-994-11 ELECT 100uF 20.00% 10V
C325 1-130-477-00 MYLAR 0.0033uF 5% 50V
C326 1-162-286-31 CERAMIC 220PF 10% 50V
C352 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C353 1-119-821-11 ELECT MELF 2.2uF 20% 50V
C354 1-130-475-00 MYLAR 0.0022uF 5% 50V
C355 1-126-045-11 ELECT 2.2uF 20.00% 50V
C356 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C357 1-119-821-11 ELECT MELF 2.2uF 20% 50V
C358 1-119-821-11 ELECT MELF 2.2uF 20% 50V
C359 1-162-282-31 CERAMIC 100PF 10% 50V
C360 1-119-821-11 ELECT MELF 2.2uF 20% 50V
C361 1-126-048-81 ELECT 10uF 20.00% 50V
C362 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C363 1-126-957-11 ELECT 0.22uF 20.00% 50V
C364 1-130-473-00 MYLAR 0.0015uF 5% 50V
C365 1-126-048-81 ELECT 10uF 20.00% 50V
C366 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C367 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C501 1-163-233-11 CERAMIC CHIP 18PF 5.00% 50V
C502 1-163-233-11 CERAMIC CHIP 18PF 5.00% 50V
C503 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C504 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C505 1-164-159-11 CERAMIC 0.1uF 50V
C506 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C507 1-126-933-11 ELECT 100uF 20.00% 16V
C508 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C521 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C901 1-126-964-11 ELECT 10uF 20.00% 50V
C902 1-126-935-11 ELECT 470uF 20.00% 16V
C903 1-126-964-11 ELECT 10uF 20.00% 50V
C904 1-104-665-11 ELECT 100uF 20.00% 10V
C905 1-126-964-11 ELECT 10uF 20.00% 50V
C906 1-126-767-11 ELECT 1000uF 20.00% 16V
C907 1-126-964-11 ELECT 10uF 20.00% 50V
C908 1-104-665-11 ELECT 100uF 20.00% 10V
C909 1-126-964-11 ELECT 10uF 20.00% 50V
C910 1-128-834-11 ELECT 470uF 20% 10V
C911 1-126-964-11 ELECT 10uF 20.00% 50V
C912 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C913 1-126-964-11 ELECT 10uF 20.00% 50V
C914 1-126-916-11 ELECT 1000uF 20.00% 6.3V
LOADING MAIN
