Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
94
R642 1-249-419-11 CARBON 1.5K 5% 1/4W F
R643 1-249-415-11 CARBON 680 5% 1/4W F
R644 1-249-417-11 CARBON 1K 5% 1/4W F
R645 1-249-419-11 CARBON 1.5K 5% 1/4W F
R646 1-247-843-11 CARBON 3.3K 5% 1/4W
R647 1-249-425-11 CARBON 4.7K 5% 1/4W F
R648 1-249-429-11 CARBON 10K 5% 1/4W
R649 1-249-415-11 CARBON 680 5% 1/4W F
R650 1-249-417-11 CARBON 1K 5% 1/4W F
R651 1-249-419-11 CARBON 1.5K 5% 1/4W F
R652 1-247-843-11 CARBON 3.3K 5% 1/4W
R653 1-249-425-11 CARBON 4.7K 5% 1/4W F
R654 1-249-429-11 CARBON 10K 5% 1/4W
R655 1-249-435-11 CARBON 33K 5% 1/4W
R660 1-247-807-31 CARBON 100 5% 1/4W
R661 1-247-807-31 CARBON 100 5% 1/4W
R662 1-247-807-31 CARBON 100 5% 1/4W
R663 1-247-807-31 CARBON 100 5% 1/4W
R664 1-247-807-31 CARBON 100 5% 1/4W
R665 1-247-807-31 CARBON 100 5% 1/4W
R666 1-247-807-31 CARBON 100 5% 1/4W
R667 1-247-807-31 CARBON 100 5% 1/4W
R668 1-247-807-31 CARBON 100 5% 1/4W
R669 1-247-807-31 CARBON 100 5% 1/4W
R670 1-247-807-31 CARBON 100 5% 1/4W
R681 1-249-425-11 CARBON 4.7K 5% 1/4W F
R682 1-249-441-11 CARBON 100K 5% 1/4W
R686 1-249-425-11 CARBON 4.7K 5% 1/4W F
R687 1-249-441-11 CARBON 100K 5% 1/4W
< SWITCH >
S601 1-418-632-11 ENCODER, ROTARY (VOLUME)
S602 1-762-875-21 SWITCH, KEYBOARD (POWER)
S603 1-762-875-21 SWITCH, KEYBOARD (lm)
S604 1-762-875-21 SWITCH, KEYBOARD (ML)
S605 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S606 1-762-875-21 SWITCH, KEYBOARD (MD A)
S607 1-762-875-21 SWITCH, KEYBOARD (MD 7)
S608 1-762-875-21 SWITCH, KEYBOARD (CD 7)
S609 1-762-875-21 SWITCH, KEYBOARD (s)
S610 1-762-875-21 SWITCH, KEYBOARD (ENTER/START)
S611 1-762-875-21 SWITCH, KEYBOARD (SYNCHRO REC)
S612 1-762-875-21 SWITCH, KEYBOARD (z MD)
S613 1-762-875-21 SWITCH, KEYBOARD (CD A)
S614 1-762-875-21 SWITCH, KEYBOARD (FUNCION)
S615 1-762-875-21 SWITCH, KEYBOARD (REPEAT/DOLBY NR)
S616 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE DIRECTION)
S617 1-762-875-21 SWITCH, KEYBOARD (z TAPE)
S618 1-762-875-21 SWITCH, KEYBOARD (s TAPE)
S619 1-762-875-21 SWITCH, KEYBOARD (TAPE h)
S620 1-762-875-21 SWITCH, KEYBOARD (TAPE H)
************************************************************
* 1-668-111-11 SW BOARD
*********
< CONNECTOR >
* CN601 1-506-486-11 PIN, CONNECTOR 7P
< SWITCH >
S601 1-572-126-21 SWITCH, PUSH (1 KEY) (REC POSITION)
S602 1-572-126-21 SWITCH, PUSH (1 KEY) (PACK OUT)
S604 1-771-264-11 SWITCH, PUSH(DETECTION)(1 KEY)
************************************************************
A-4426-954-A TC BOARD, COMPLETE
******************
< CAPACITOR >
C402 1-130-479-00 MYLAR 0.0047uF 5% 50V
C403 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C404 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C405 1-126-795-11 ELECT 10uF 20.00% 50V
C406 1-115-871-11 ELECT 1uF 20.00% 50V
C407 1-115-870-11 ELECT 0.47uF 20.00% 50V
C408 1-126-795-11 ELECT 10uF 20.00% 50V
C409 1-137-194-81 MYLAR 0.47uF 5.00% 50V
C410 1-162-290-31 CERAMIC 470PF 10% 50V
C411 1-126-795-11 ELECT 10uF 20.00% 50V
C412 1-115-870-11 ELECT 0.47uF 20.00% 50V
C413 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C414 1-126-795-11 ELECT 10uF 20.00% 50V
C415 1-126-794-11 ELECT 4.7uF 20.00% 50V
C416 1-126-382-11 ELECT 100uF 20.00% 10V
C417 1-126-382-11 ELECT 100uF 20.00% 10V
C420 1-162-290-31 CERAMIC 470PF 10% 50V
C431 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C432 1-126-382-11 ELECT 100uF 20.00% 10V
C433 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C435 1-130-483-00 MYLAR 0.01uF 5% 50V
C436 1-126-795-11 ELECT 10uF 20.00% 50V
C437 1-124-282-00 ELECT 22uF 20.00% 16V
C438 1-137-427-11 MYLAR 120PF 5.00% 50V
C439 1-162-288-31 CERAMIC 330PF 10% 50V
C440 1-162-209-31 CERAMIC 27PF 5.00% 50V
C452 1-130-479-00 MYLAR 0.0047uF 5% 50V
C453 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C454 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C455 1-126-795-11 ELECT 10uF 20.00% 50V
C456 1-115-871-11 ELECT 1uF 20.00% 50V
C457 1-115-870-11 ELECT 0.47uF 20.00% 50V
C458 1-126-795-11 ELECT 10uF 20.00% 50V
C459 1-137-194-81 MYLAR 0.47uF 5.00% 50V
C461 1-104-664-11 ELECT 47uF 20.00% 16V
C462 1-126-960-11 ELECT 1uF 20.00% 50V
C463 1-136-153-00 FILM 0.01uF 5% 50V
C464 1-130-481-00 MYLAR 0.0068uF 5% 50V
C465 1-130-481-00 MYLAR 0.0068uF 5% 50V
C466 1-136-155-00 FILM 0.015uF 5% 50V
C467 1-126-961-11 ELECT 2.2uF 20.00% 50V
C468 1-137-150-11 FILM 0.01uF 5.00% 100V
C471 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C481 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C482 1-126-382-11 ELECT 100uF 20.00% 10V
C483 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C485 1-130-483-00 MYLAR 0.01uF 5% 50V
C486 1-126-795-11 ELECT 10uF 20.00% 50V
C487 1-124-282-00 ELECT 22uF 20.00% 16V
C488 1-137-427-11 MYLAR 120PF 5.00% 50V
PANEL SW TC
