Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
109
HCD-M90
C647 1-126-933-11 ELECT 100uF 20% 16V
C648 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C649 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C650 1-126-160-11 ELECT 1uF 20% 50V
C668 1-104-905-11 CAPACITOR 0.22F 5.5V
C673 1-124-234-00 ELECT 22uF 20% 16V
C690 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C801 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C802 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C803 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C804 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C824 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN506 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN507 1-779-278-11 CONNECTOR, FFC (LIF (NON-ZIF)) 10P
CN801 1-568-838-11 CONNECTOR, FFC 21P
* CN802 1-506-988-11 PIN, CONNECTOR (PC BOARD) 6P
CN803 1-779-274-11 CONNECTOR, FFC (LIF (NON-ZIF)) 6P
CN804 1-784-778-11 CONNECTOR, FFC 17P
CN806 1-784-786-11 CONNECTOR, FFC 25P
* CN809 1-506-985-11 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
D333 8-719-991-33 DIODE 1SS133T-77
D334 8-719-200-82 DIODE 11ES2
D602 8-719-991-33 DIODE 1SS133T-77
D604 8-719-991-33 DIODE 1SS133T-77
D620 8-719-991-33 DIODE 1SS133T-77
D622 8-719-991-33 DIODE 1SS133T-77
D623 8-719-991-33 DIODE 1SS133T-77
D624 8-719-991-33 DIODE 1SS133T-77
< FERRITE BEAD >
FB626 1-469-144-21 FERRITE 0uH
FB627 1-469-144-21 FERRITE 0uH
FB628 1-469-144-21 FERRITE 0uH
FB629 1-469-144-21 FERRITE 0uH
< IC >
IC302 8-759-491-32 IC TC74VHCT04AF (EL)
IC306 6-801-363-01 IC M30620MCN-A11FP
IC602 8-759-533-04 IC M62703ML-E1
IC605 8-759-686-72 IC uPC29L04J-T
IC614 8-759-646-52 IC KIA7805API
< SHORT >
JR100 1-216-864-11 SHORT CHIP 0
JR101 1-216-864-11 SHORT CHIP 0
JR102 1-216-864-11 SHORT CHIP 0
JR103 1-216-864-11 SHORT CHIP 0
JR302 1-216-864-11 SHORT CHIP 0
JR304 1-216-864-11 SHORT CHIP 0
JR305 1-216-864-11 SHORT CHIP 0
JR306 1-216-864-11 SHORT CHIP 0
JR307 1-216-864-11 SHORT CHIP 0
JR604 1-216-864-11 SHORT CHIP 0
JR605 1-216-864-11 SHORT CHIP 0
JR606 1-216-864-11 SHORT CHIP 0
< COIL >
L301 1-412-002-31 INDUCTOR 4.7uH
L302 1-412-002-31 INDUCTOR 4.7uH
L303 1-410-324-11 INDUCTOR 4.7uH
< TRANSISTOR >
Q618 8-729-055-91 TRANSISTOR SRA2202SF
Q619 8-729-034-51 TRANSISTOR KTC3875
Q635 8-729-037-02 TRANSISTOR KTA1266Y-AT
Q637 8-729-055-94 TRANSISTOR SRC1202SF
< RESISTOR >
R102 1-216-841-11 METAL CHIP 47K 5% 1/10W
R103 1-216-833-11 METAL CHIP 10K 5% 1/10W
R104 1-216-833-11 METAL CHIP 10K 5% 1/10W
R119 1-216-833-11 METAL CHIP 10K 5% 1/10W
R121 1-216-833-11 METAL CHIP 10K 5% 1/10W
R128 1-216-833-11 METAL CHIP 10K 5% 1/10W
R362 1-216-845-11 METAL CHIP 100K 5% 1/10W
R389 1-216-815-11 METAL CHIP 330 5% 1/10W
(CH)
R389 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(US, CND)
R389 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(SP, AUS)
R389 1-216-864-11 SHORT CHIP 0 (AEP, UK)
R401 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R402 1-216-821-11 METAL CHIP 1K 5% 1/10W
R403 1-216-821-11 METAL CHIP 1K 5% 1/10W
R404 1-216-821-11 METAL CHIP 1K 5% 1/10W
R405 1-216-821-11 METAL CHIP 1K 5% 1/10W
R406 1-216-821-11 METAL CHIP 1K 5% 1/10W
R407 1-216-821-11 METAL CHIP 1K 5% 1/10W
R409 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R417 1-216-833-11 METAL CHIP 10K 5% 1/10W
R418 1-216-821-11 METAL CHIP 1K 5% 1/10W
R419 1-216-821-11 METAL CHIP 1K 5% 1/10W
R420 1-216-821-11 METAL CHIP 1K 5% 1/10W
R422 1-216-821-11 METAL CHIP 1K 5% 1/10W
R423 1-216-821-11 METAL CHIP 1K 5% 1/10W
R425 1-216-821-11 METAL CHIP 1K 5% 1/10W
R427 1-216-821-11 METAL CHIP 1K 5% 1/10W
R429 1-216-809-11 METAL CHIP 100 5% 1/10W
R430 1-216-809-11 METAL CHIP 100 5% 1/10W
R433 1-216-821-11 METAL CHIP 1K 5% 1/10W
R435 1-216-821-11 METAL CHIP 1K 5% 1/10W
R436 1-216-821-11 METAL CHIP 1K 5% 1/10W
R437 1-216-821-11 METAL CHIP 1K 5% 1/10W
R438 1-216-821-11 METAL CHIP 1K 5% 1/10W
R439 1-216-821-11 METAL CHIP 1K 5% 1/10W
R440 1-216-821-11 METAL CHIP 1K 5% 1/10W
R441 1-216-821-11 METAL CHIP 1K 5% 1/10W
R442 1-216-864-11 SHORT CHIP 0
R443 1-216-821-11 METAL CHIP 1K 5% 1/10W
R444 1-216-821-11 METAL CHIP 1K 5% 1/10W
R445 1-216-821-11 METAL CHIP 1K 5% 1/10W
Ver 1.3
CONTROL (Suffix-12)
