Sony HCD-M90 - Printed Wiring Board - RF-240 Board (Suffix-22); RF-240 Board Component Layout (Suffix-22)

HCD-M90
3838
A
DVD
BOARD
CN010
A
B
C
D
1 2 3 4 5 6 7 8
IC001
22
(22)
22
(22)
B
DVD
BOARD
CN009
OPTICAL PICK-UP
BLOCK
(KHM-240AAA) (TYPE A)
(KHM-270AAA) (TYPE B)
6-10. PRINTED WIRING BOARD – RF-240 Board (Suffix-22) – • See page 35 for Circuit Boards Location. • Refer to servicing notes (page 8) for discrimination of TYPE A/B.
(Page 56)
(Page 56)
• Semiconductor
Location
Ref. No. Location
D001 D-2
D004 D-3
IC001 B-3
Q001 D-3
Q002 D-3
Ver 1.3
