HCD-M90
14
3-8. CONTROL BOARD, NOISE SHIELD CASE
3-9. DAC BOARD
6
two screws
(BVTP3
×
8)
7
5
two leads (with connector)
5
lead (with connector)
1
wire (flat type) (FFC) (6 core)
(CN803)
1
wire (flat type) (FFC) (13 core)
(CN506)
1
wire (flat type) (FFC) (10 core)
(CN507)
3
control board
2
two screws
(BVTP3
×
8)
4
connector
(CN008)
8
noise shield case
6
two screws
(BVTP3
×
8)
3
terminal
3
terminal
4
DAC board
2
screw
(DIA. 2.6
×
8)
2
screw
(DIA. 2.6
×
8)
1
wire (flat type) (FFC) (5 core)
(CN300)
