Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
119
HCD-M90
< FERRITE BEAD >
FB510 1-469-144-21 FERRITE 0uH
FB511 1-469-144-21 FERRITE 0uH
FB512 1-469-144-21 FERRITE 0uH
< JACK >
J301 1-794-453-11 JACK (PHONES)
< SHORT >
JR502 1-216-864-11 SHORT CHIP 0
JR503 1-216-864-11 SHORT CHIP 0
< COIL >
L101 1-412-006-31 INDUCTOR 10uH
L201 1-412-006-31 INDUCTOR 10uH
L202 1-412-002-31 INDUCTOR 4.7uH
L203 1-412-002-31 INDUCTOR 4.7uH
L204 1-412-002-31 INDUCTOR 4.7uH
L205 1-412-002-31 INDUCTOR 4.7uH
< RESISTOR >
R515 1-216-819-11 METAL CHIP 680 5% 1/10W
R887 1-216-821-11 METAL CHIP 1K 5% 1/10W
R890 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R891 1-216-821-11 METAL CHIP 1K 5% 1/10W
R893 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S810 1-786-220-11 SWITCH, KEY BOARD (CD SYNCHRO)
S814 1-786-220-11 SWITCH, KEY BOARD (DIRECTION)
S816 1-786-220-11 SWITCH, KEY BOARD (REPEAT, FM MODE)
S819 1-786-220-11 SWITCH, KEY BOARD
(PLAY MODE, TUNING MODE)
**************************************************************
1-685-428-12 JACK BOARD
***********
< CAPACITOR >
C897 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C898 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
< CONNECTOR >
* CNP602 1-568-943-11 PIN, CONNECTOR 5P
< DIODE >
D801 8-719-988-61 DIODE 1SS355TE-17
D803 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB510 1-469-144-21 FERRITE 0uH
FB511 1-469-144-21 FERRITE 0uH
FB512 1-469-144-21 FERRITE 0uH
< JACK >
J301 1-794-453-11 JACK (PHONES)
< SHORT >
JR502 1-216-864-11 SHORT CHIP 0
JR503 1-216-864-11 SHORT CHIP 0
< COIL >
L101 1-412-006-31 INDUCTOR 10uH
L201 1-412-006-31 INDUCTOR 10uH
L202 1-412-002-31 INDUCTOR 4.7uH
L203 1-412-002-31 INDUCTOR 4.7uH
L204 1-412-002-31 INDUCTOR 4.7uH
L205 1-412-002-31 INDUCTOR 4.7uH
< RESISTOR >
R515 1-216-819-11 METAL CHIP 680 5% 1/10W
R887 1-216-821-11 METAL CHIP 1K 5% 1/10W
R890 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R891 1-216-821-11 METAL CHIP 1K 5% 1/10W
R893 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S810 1-786-220-11 SWITCH, KEY BOARD (CD SYNCHRO)
S814 1-786-220-11 SWITCH, KEY BOARD (DIRECTION)
S816 1-786-220-11 SWITCH, KEY BOARD (REPEAT, FM MODE)
S819 1-786-220-11 SWITCH, KEY BOARD
(PLAY MODE, TUNING MODE)
**************************************************************
1-676-599-11 LOADING BOARD
**************
< CONNECTOR >
* CN1 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S1 1-771-799-11 SWITCH, LEVER SLIDE
(DISC TRAY OPEN/CLOSE DETECT)
**************************************************************
A-4729-477-A MAIN BOARD, COMPLETE (AEP, UK)
A-4729-478-A MAIN BOARD, COMPLETE (US, CND)
A-4729-479-A MAIN BOARD, COMPLETE (AUS)
A-4729-480-A MAIN BOARD, COMPLETE (SP)
*********************
4-217-354-11 BUSHING, INSULATING
4-230-078-01 SCREW, +BV TAPPING
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C101 1-126-963-11 ELECT 4.7uF 20% 50V
C102 1-126-963-11 ELECT 4.7uF 20% 50V
C103 1-126-163-11 ELECT 4.7uF 20% 50V
C104 1-126-963-11 ELECT 4.7uF 20% 50V
C106 1-126-163-11 ELECT 4.7uF 20% 50V
C107 1-162-965-11 CERAMIC CHIP 0.0015uF 5% 50V
C108 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C109 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C110 1-126-963-11 ELECT 4.7uF 20% 50V
C111 1-115-156-11 CERAMIC CHIP 1uF 10V
JACK (Suffix-11) JACK (Suffix-12) LOADING MAIN (Suffix-14)
